Full Product Specification
| Name | Value | Metric Value |
|---|---|---|
| CD Now Program | No | |
| Overall Height | 6.5 in | 165.1 mm |
| Caster Swivel Radius | 4 in | 101.6 mm |
| Mounting Type | Top Plate | |
| Capacity - Dynamic | 350 lbs | 159.09 kg |
| Temperature Maximum | 180 °F | 82.2 °C |
| Temperature Minimum | -45 °F | -42.8 °C |
| Greasable Axle | Yes | |
| Wheel Diameter | 5 in | 127 mm |
| Wheel Width | 2 in | 50.8 mm |
| Wheel (non-Marking) | Yes | |
| Wheel (count) | 1 | |
| Wheel Tread Material | Thermoplastic Rubber (TPR) | |
| Wheel Tread Color | Grey | |
| Wheel Hub Material | Polyolefin | |
| Wheel Hub Color | Grey | |
| Wheel Face | Flat | |
| Wheel Hub Type: Spoked, Solid | Solid | |
| Wheel Bearing | Roller Bearing | |
| Wheel Durometer | 90A | |
| Wheel Thread Guard | No | |
| Wheel Zerk | No | |
| Rig Finish / Coating | Zinc Plated | |
| Rig Zerk | Yes | |
| CE Mark | No | |
| Wheel Tread Category | Rubber | |
| Swivel Type | Swivel | |
| Plate Drilled / Tapped | No | |
| Plate Number of Bolt Holes | 4 | |
| Plate Width | 4.5 in | 114.3 mm |
| Plate Length | 4 in | 101.6 mm |
| Brake | No |
